    API C90 J55 Oil Casing Pipe Copper Coated P110 , T95 Casing Oil And Gas

    Ask Lasest Price
    Brand Name : Best
    Model Number : 114.3 - 508 mm
    Certification : API
    Price : 600 usd/ton
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 100000Ton/Month
    Delivery Time : 5-8 working days
    • Product Details
    • Company Profile

    API C90 J55 Oil Casing Pipe Copper Coated P110 , T95 Casing Oil And Gas

    Product Name : API 5CT J55 oil casing seamless pipe Steel Grades: K55, J55, L80-1 ,N80,C90,C95, P110, T95


    Standard: API 5CT, API 5D
    Steel Grades: K55, J55, L80-1 ,N80,C90,C95, P110, T95
    Size: 2 3/8"-4 1/2"*0.167"-0630"


    Casing Pipe

    Tubing steel pipe

    Oil Casing Pipe/Steel Pipe

    Including ordinary casing, Anti-collapse casing, Anti-corrosion casing, Hi-strength casing

    Serves as walls of a well;

    Standard: API 5CT

    Steel Grades: k55, J55, L80,N80,C90,C95, P110 T95, M65,E75,X95,G105,S135


    1) Tubing


    OD: 2 3/8" -----4 1/2"

    WT: 0.167" -----0.630"


    Note: P : Plain end, N: Non upset, U: External upset, T&C: Threaded and coupled.


    2) Casing


    OD: 2 3/8“ ----20"

    WT: 0.205" --- 0.5"

    Note: P: Plain end, S: Short round thread, L: Long round thread


    Length

    R1 R2 R3

    Tubing 6.10 -7.32 m 8.53-9.75m 11.58-12.80m

    Casing 4.88 - 7.62m 6.72 -10.36m 10.36 - 14.63m


    3) Drill Pipe

    OD: 2 3/8" - 5 1/2"

    WT: 0.280" - 0.449"

    Note: EU: External upset , IEU: Internal & External upset

    Thread of tool joint are right-hand or left hand


    API Oil pipe, Casing pipe


    Type

    Label 1

    (in)

    Outside diameter

    (mm)

    Wall thickness

    (mm)

    GradeType of threadLength
    Casing4-1/2114.305.21-8.56H40-P110

    STC


    LC


    BC

    4.88-13.5m
    5127.005.59-12.70H40-P110
    5-1/2139.706.20-22.22H40-P110
    6-5/8168.287.32-12.06H40-P110
    7177.805.87-22.22H40-P110
    Oil pipe2-3/860.324.24-8.53H40-P110

    NU


    EU

    6.1-12.8m
    2-7/873.025.51-11.18H40-P110
    3-1/288.905.49-13.46H40-P110
    4101.605.74-15.49H40-P110
    4-1/2114.306.88-16.00H40-P110

    GradeYield Strength(Mpa)Tensile Strength(Mpa)Hardness
    J55379-522>517
    K55379-552>655
    N80552-758>689
    L80-1552-655>68923-241
    C90621-724>68925.4-255
    C95655-758>724
    T95655-758>72425.4-255
    P110758-965>862

    API 5CT J55 oil casing seamless pipe Pictures
